TIG welding machine LCD 203A

TIG Welding Machine LCD 203A

Country of origin: Netherlands, warranty period – 24 months

LCD 203A is a compact and versatile TIG welding machine suitable for both TIG and MMA (electrode) welding. It is designed for working with metals of various thicknesses – from thin sheets to more robust constructions. The welding unit operates on a single-phase 230 V power supply, and its performance parameters allow efficient welding operations both in workshops and on mobile job sites. Thanks to its compact design and weight of only 15 kg, the unit is easy to transport and convenient to use in confined spaces.

Features:

• TIG and MMA welding modes – versatile for a wide range of tasks
• Suitable for welding stainless steel and standard structural materials
• High ignition voltage (82 V) facilitates arc start
• Easy to use due to its compact size and light weight
• Protection class IP21S – resistant to dust and moisture droplets

Technical Specifications:

• Frequency: 50/60 Hz
• Voltage: 230 V – single phase
• Ignition voltage: 82 V
• Nominal input current: 33.5 A
• Duty cycle at 40 °C: 30% – 200 A
• Welding current range:
• TIG: 10–200 A
• MMA: 20–180 A
• Protection class: IP21S

Product dimensions:

• Length: 480 mm
• Width: 240 mm
• Height: 480 mm
• Weight: 15.0 kg

Packaging dimensions:

• Length: 480 mm
• Width: 240 mm
• Height: 480 mm
• Weight: 19.0 kg
