TIG welding machine Hugong Novi AC/DC 233

TIG Welding Machine Hugong Novi AC/DC 233

Country of origin: Netherlands, warranty period – 24 months

The Hugong NVT233ACDC is an advanced, portable TIG welding machine from the NOVI series, designed for operation with both alternating current (AC) and direct current (DC). This digital 4-in-1 inverter supports HF AC TIG, DC TIG, Lift-TIG, and MMA welding modes, making it ideal for a wide range of tasks – from thin sheet metal to industrial constructions. The device is built on IGBT technology and features an HDVision LCD display and Cortex M4 processor, ensuring highly precise control of the welding process. With synergic control and the unique Soft-Arc® HF ignition technology, the arc ignition success rate exceeds 99%, even on thin or challenging materials. The AC ARCACE™ function ensures a stable arc when welding aluminum or performing spot welding.

In TIG mode, settings such as pulse control, pre- and post-gas timing, slope up/down, and 2T/4T operation are fully adjustable. In MMA mode, integrated features such as Hot Start, Arc Force, and Anti-Stick ensure easier and more reliable electrode welding.

Features:

• 4-in-1 TIG welding modes: HF AC/DC TIG, Lift-TIG, and MMA – a versatile solution for various applications
• HDVision control with synergic mode: clear LCD display and intuitive adjustments, convenient even for repetitive welding tasks
• Soft-Arc® and AC ARCACE™ stabilization technologies: more than 99% successful arc ignition – especially suitable for thin aluminum, stainless steel, and precision TIG welding
• Shock-resistant ABS housing: durable industrial design – built for heavy-duty use

Technical Specifications:

• Frequency: 50/60 Hz
• Voltage: 230 V – single phase
• Ignition voltage: 69 V
• Nominal input current: 27 A
• Duty cycle at 20 °C: 60% – 230 A
• Duty cycle at 40 °C: 30% – 230 A
• Welding current range:
• AC TIG: 15–230 A
• DC TIG: 5–230 A
• MMA: 10–180 A

Product dimensions:

• Length: 538 mm
• Width: 241 mm
• Height: 402 mm
• Weight: 18.0 kg

Included in the package:

• TIG torch HG PRO 26 – 4 m
• Ground cable with clamp – 3 m, 16 mm²
• Gas hose – 3 m with 2 hose clamps and brass coupling
• TIG accessory kit
