TIG welding machine Hugong ETIG160

TIG Welding Machine Hugong ETIG160

Country of origin: Netherlands, warranty period – 24 months

The Hugong ETIG160 is a compact and portable TIG/MMA welding machine designed for precise welding of carbon steel, low-alloy steel, and stainless steel. Utilizing modern IGBT inverter technology, high-frequency (HF) arc ignition, and a clear digital display, this unit is ideal for light industrial work, maintenance, and mobile applications.

The ETIG160 supports DC HF TIG, Lift-TIG, and MMA welding modes, with adjustable parameters such as welding current, pre- and post-gas time, and peak and base current levels. The machine is also equipped with a memory function, allowing users to save and recall specific welding settings—especially convenient for repetitive welding tasks.

Weighing only 6.8 kg, this unit is highly mobile without compromising on power or ease of control.

Features:

• Compact TIG (HF) / Lift-TIG / MMA welding machine – versatile for various applications
• Non-contact HF arc ignition – for cleaner and more precise TIG welding
• Continuously adjustable current – precise control for both TIG and MMA modes
• Memory function – store and quickly recall preferred welding parameters
• Durable ABS housing – impact-resistant and built for demanding use

Technical Specifications:

• Frequency: 50/60 Hz
• Voltage: 230 V – single phase
• Ignition voltage: 82 V
• Input power: 6.6 kVA
• Welding current range:
• TIG: 10–160 A
• MMA: 20–160 A
• Duty cycle:
• At 20 °C: 60% – 160 A
• At 40 °C: 35% – 160 A
• Protection class: IP21S

Product dimensions:

• Length: 394 mm
• Width: 154 mm
• Height: 293 mm
• Weight: 6.8 kg

Packaging dimensions:

• Length: 450 mm
• Width: 325 mm
• Height: 345 mm
• Weight: 13.70 kg

Included in the Package:

• TIG torch HG PRO 26 – 4 m
• Ground cable with clamp – 3 m, 16 mm²
• Gas hose – 3 m with NW5 coupling
• TIG accessory kit
