Spot welding machine POWER SPOT 5700 CEBORA
Spot welding machine POWER SPOT 5700 CEBORA
New

Spot welding machine POWER SPOT 5700 CEBORA

  • SKU: BD70777
2,499.00 €

Prices shown include tax

Send Message

Description

Spot welding machine POWER SPOT 5700 CEBORA

Country of origin: Italy, warranty period – 24 months

Optional accessories listed below can be purchased for this unit!

CEBORA POWER SPOT 5700 is a compact and lightweight spot welding machine operating on capacitor discharge technology. It enables extremely fast welding (within milliseconds) of aluminum or steel studs up to Ø 8 mm to ferrous and non-ferrous metals without affecting the structure of the base sheet. It is ideal for automotive body repair, vehicle customization, internal component mounting, and more.

Functions:
  • Welding gun with double ground lead and clamps
  • Designed for welding aluminum or steel studs
  • Easy access even in hard-to-reach areas
The LCD screen displays:
  • selection of stud material and diameter
  • selection of base material for stud welding
  • working voltage input
  • applied force input
  • weldability check between stud and base material
Technical specifications:
  • Power supply: 115 V 50/60 Hz ±10 % or 230 V 50/60 Hz ±10 %
  • Fuse: 16 A (115 V) / 10 A (230 V)
  • Energy adjustment range: 50 J – 1500 J
  • Capacitor capacity: 66 mF
  • Max. stud diameter: M8
  • Protection class: IP23S
  • Weight: 15 kg
  • Dimensions (LxWxH): 176 x 370 x 401 mm
Available accessories:
  • M4x15 threaded rivets, aluminum (package of 100 pcs)
  • Special washers (package of 5 pcs)
  • 3-point spacer for gun
  • Stud holders for M3, M4, M5, M6, M8
