Single column lift REDATS L-121F

Single column lift REDATS L-121F

What type of lift?

It is a single column, mobile car lift. It boasts a lifting capacity of 2.8 tones, making it easy to use for cars and smaller vans.

Select it if you are looking for a lift that:

• saves your service space - takes up half the space of a two-column lift
• easy to move - a construction similar to a pallet truck
• it does not require floor mounting
• perfect for body and painting work
• perfect for smaller mechanical jobs such as brakes

Requirements:

• Closed room
• Smooth floor
• Concrete surface
• Power supply: 230V

Technical parameters:

• Maximum capacity: 2.8 tons
• Type: automatic
• Power supply: 230V 50Hz
• Time to full take-off: 60 s
• Rear arm length: 435 - 685 mm
• Front arm length: 640 - 970 mm
• Column base size: 1140 x 1790 mm
• Lifting height: 1900 mm
• Power: 2.2 kW
• Folding arms: YES
• Dimensions: 3080 x 2470 x 2690 mm
