Semi-automatic truck wheel balancing machine BD-790

Semi-automatic truck wheel balancing machine BD-790, with wheel lifting mechanism

Features:

• The main wheel balancing shaft is 40 mm in diameter. Longitudinal surface grinding and an excellent heat treatment process were applied to its processing. The aluminum drive pulley is corrosion resistant. For these reasons, the main shaft can be used safely and reliably for many years.
• Ruler - made of aluminum alloy, with extremely accurate measurement parameters, so with its help you will be able to get very accurate measurement results. Using this ruler, you will be able to more easily mark the place where the balancing weight should be glued.
• Control panel - it is equipped with an LED screen with special buttons, with the help of which you can enter the necessary data or select a balancing program. Also, other LEDs will show you the parameters and results of the wheel imbalance and the location of the balance.
• Side compartments are newly designed, large and practical cavities that will give you the opportunity to store various machine accessories in an accessible place at all times.
• Wheel guard is a standard guard that can be used to control the start and stop operations of the balancing machine.
• Balancing Operations – The balancer has full wheel balancing operations such as dynamic balancing, static balancing, 3 ALU rim balancing modes and freely adjustable OPT function.
• Wheel lifting mechanism - balancing machines are equipped with wheel lifting equipment.

Technical parameters:

• Diameter of balanced rims: 10" - 26"
• Maximum wheel diameter: 1200 mm
• Wheel width: 1.5" - 20" | 38 - 510 mm
• Rotation speed, during balancing: 200 rpm
• Maximum wheel weight: 150 kg
• Balancing accuracy: ± 10 g
• Motor power: 0.25 kW

Standard equipment:

• Balancing cones of different dimensions x 5 pcs.
• Wheel width measuring ruler x 1 pc.
• Quick release nut, heavy duty x 1 pc.
• Pliers, for working with weights x 1 pc.
• Mounting adapter with birth protection x 1 pc.
