Screw air compressor with frequency control 30 kW Comprag

Screw Air Compressor with Frequency Control 30 kW Comprag

The screw air compressor with frequency control 30 kW Comprag is available in the following options:

• 5-8 bar, 5100 l/min
• 5-10 bar, 4600 l/min

Functions:

• The FV-Series oil-lubricated screw compressors produce industrial compressed air and can optionally be equipped with a refrigeration dryer, achieving air purity up to class 4-4-4 according to ISO 8573-1:2010.
• Frequency control – the compressor automatically adjusts motor speed according to real air demand, maintaining constant system pressure and reducing energy consumption.
• No idle running – the compressor consumes no electricity when there is no air demand.
• Stable system pressure – eliminates pressure fluctuations and pulsations in the compressed air network.
• Reduced air losses and lower maximum system pressure – extending equipment service life and reducing operating costs.
• Soft start – the frequency inverter reduces starting current, extending the service life of the motor and electrical components.
• A modern, energy-efficient screw air-end ensures long-term reliability even under intensive operating conditions.
• The professional t-Log microprocessor controller automatically manages operation and displays pressure, temperature, and running time.
• A reliable electric motor with a high efficiency rating, bearings from leading manufacturers, energy reserve, and overheat protection.
• An efficient three-stage oil separation system – oil is separated by centrifugal, gravitational, and filtration forces, ensuring the residual oil content in the air does not exceed 3 mg/m³.
• Easy maintenance – all filters and separators are easily accessible, ensuring fast and convenient servicing.
• Quiet operation – noise level only 72 dB(A), making the unit suitable for work environments where comfort and low noise are important.

Features of the FV-Series screw compressors:

• Professional controller
• Efficient and reliable electric motor
• Screw-type air-end
• Effective separation system

Technical specifications:

• Motor power: 30 kW
• Rated voltage: 3/380–420 V/50 Hz
• Noise level: 72 dB(A)
• Connection: 1-1/4"
• Length: 1400 mm
• Width: 1000 mm
• Height: 1500 mm
• Weight: 725 kg
