Scissor lift ATH-Cross Lift 50 OG

Scissor lift ATH-Cross Lift 50 OG

Scissor lift for surface or surface mounting (with additional ramps), lifting capacity 5000 kg, with integrated central scissor lift

High-precision production by laser cutting and robot welding

Robust and less sensitive hydraulic drive that requires almost no maintenance

Suitable for ground mounting or surface mounting with optional kit; for passenger cars and vehicles with a long wheelbase; platform length 5.00 m

Great lift for wheel alignment; with recesses for turntables at the front, pre-assembled pneumatically lockable sliding plates at the rear and integrated central lifting shears (central lifting shear capacity: 4000 kg, lifting height: 450 mm)

Can be used universally with flat platforms and rails for optional rolling

Series with rails for additional rolling jack (ATH AF2500P), ramp stabilization rods, 24V LED lighting kit (629020) with metal cover and on / off switch, platform extensions with built-in game detector, maximum load 2.6 t

Without lifting lever

The control of the hydraulic sequence (master and slave cylinders) ensures even raising and lowering of the shears; the integrated light barrier constantly monitors the synchronization of the lift

Pneumatic cut-out unlocking, emergency lowering system for lowering in the event of a power failure, CE stop and audible signal

Lifting and lowering are controlled by a button

Pneumatic cut-out unlocking, protection against loose ropes, emergency lowering system for lowering in the event of a power failure, CE stop and audible signal

Partial galvanizing, double powder coating and platform protection from a special polymer

Great lift for car repair, wheel alignment, headlight light and steering assistance system

Technical parameters:

Packaging - 5060 x 680 x 500 mm

Color - anthracite gray / black

Weight - 2575 kg

Foundation depth without floor covering - 200 mm

Concrete strength - C20 / 25

Supply voltage (electricity) - 3 / 400V / 50Hz

Fuse Protection - 3C16 A

Driving power - 3.5 kW

Nominal lifting capacity - 5000 kg

Total length with ramps - 5575 mm

The total width of the platform is 610 mm

The total length of the platform is 5000 mm

Overall width - 2200 mm

Synchronization systems - photoelectric sensor / master and slave cylinder

Lifting / lowering time - 70/60 s

Lifting height max. - 1870 mm

Lifting height without wheels - 450 mm

Oil content approx. - 18 l

The nominal lifting capacity of the wheelless lift is 4000 kg

Compressed air connection - 8 bar
