Pneumohydraulic pit lift AC Hydraulic GGD150F

Pneumo-hydraulic pit jack AC Hydraulic GGD150F 15t

Country of origin: Denmark, warranty period – 3 years for hydraulics and 10 years for frame components

Universal pneumo-hydraulic jack with a telescopic cylinder, suitable for use in service pits or under vehicle lifts. Perfect for various lifting tasks, especially gearbox removal and installation. Its ergonomic design and safety features ensure convenient and safe operation in workshops.

Functions:

• Suitable for use in pits or under lifts
• Ideal for gearbox installation and removal
• Foot control allows precise height adjustment
• Spring-loaded castor locks prevent movement when lifting over 800 kg
• Equipped with emergency release and overload valve

Technical specifications:

• Lifting capacity: 15 tons
• Stroke: 1285 mm
• Minimum height: 920 mm
• Maximum height: 2205 mm
• Jack length: 845 mm
• Jack width: 1005 mm
• Cylinder diameter: 60 mm
• Required air pressure: 8.5–12 bar
• Required air flow: 350 L/min
• Weight: 220 kg
