Pneumo-hydraulic jacking beam 4 tons

Pneumo-hydraulic jacking beam 4 tons

Manufacturer: Falco Sallevatori, Netherlands

This air operated hydraulic jacking beam from Falco Sollevatori is an great addition for any four column & scissor lift installed in automotive workshops used for conducting maintenance. The jack can be easily installed and positioned thanks to the special ball bearing steel rollers, which have a universal adjustable position. The Falco jacking beam has an integrated two-stage pump, this system provides an automatic fast lifting stroke without weight and a slow controllable stroke when the jacking beam is lifting the vehicle.

It comes with square saddles and cup-shaped height adapters to increase the lifting height, it’s equipped with rubber lifting pads for protection of the car body.

With the two-speed lowering system, a loaded car can be safely lowered with minimal decrease in speed. Once the load is of the jacking beam the lowering speed will automatically increase to work efficiently and more safe.

Technical parameters:

• Used air pressure: 7.5 - 12 bar
• Carrying capacity: 4000 kg
• Minimum lifting height: 261 mm
• Maximum lifting height: 511 mm
• Stroke: 250 mm
• Lengths of telescopic arms: 780 - 1515 mm
• Lift width with attachments: 870 – 1290 mm
• Platform dimensions: 755 x 196 mm
• Height of adapters: 75 mm
• Axle lift length: 443 mm
• Axle lift width: 875 mm
• Axle lift height: 230 mm
• Axle lift weight: 176 kg
