Pneumatic-hydraulic pit-mounted jack AC Hydraulic GGD150S
Pneumatic-hydraulic pit-mounted jack AC Hydraulic GGD150S
Pneumatic-hydraulic pit-mounted jack AC Hydraulic GGD150S
Pneumatic-hydraulic pit-mounted jack AC Hydraulic GGD150S

Pneumatic-hydraulic pit-mounted jack AC Hydraulic GGD150S

  • SKU: BD13420
7,355.00 €

AC-HYDRAULIC AC-HYDRAULIC
Prices shown include tax
Add to Cart

Send Message

Description

Pneumatic-hydraulic pit-mounted jack AC Hydraulic GGD150S


AC-Hydraulic, Denmark; Warranty: 3 years for hydraulics and 10 years for body parts

Pneumatic-hydraulic pit-mounted hoist with sliding telescopic cylinder

Description:

- The sliding cylinder ensures wide reach under the car and allows the mechanic to move freely in the pit
- Extremely well suited for gearbox assembly and assembly
- Integrated foot pump for easy and precise adjustment
- Fast and accurate pneumatic-hydraulic axle hoist with high-speed cylinder
- Wheel support with integrated springs prevents unwanted movement when lifting over 800 kg
- Base housing castors with integrated bearings for optimum maneuverability
- Feet-controlled, leaving hands free
- Emergency release with overload valve for optimum safety
- Manufacturer: Denmark
- Warranty: 3 years

Specification:

- Lifting capacity: 15/15 tonnes
- Stroke of piston: 1285 mm
- Minimum height: 905 mm
- Maximum height: 2190 mm
- Lift length: equal to pit width
- Lift width: 940 mm
- Cylinder diameter: 60 mm
- Required compressed air pressure: 8.5 - 12 bar
- Required compressed air flow: 350 L / min
- Weight: 250 kg
- 100 x 100 x 10 mm rails should be installed at the bottom edges of the pit
