Pneumatic-hydraulic jack for high-base machines AC Hydraulic 65-1H
Pneumatic-hydraulic jack for high-base machines AC Hydraulic 65-1H
Pneumatic-hydraulic jack for high-base machines AC Hydraulic 65-1H
Pneumatic-hydraulic jack for high-base machines AC Hydraulic 65-1H
Pneumatic-hydraulic jack for high-base machines AC Hydraulic 65-1H

Pneumatic-hydraulic jack for high-base machines AC Hydraulic 65-1H

  • SKU: BD13680
4,235.00 €

Prices shown include tax

Send Message

Description

Pneumatic-hydraulic jack for high-base machines AC Hydraulic 65-1H

AC-Hydraulic, Denmark; Warranty: 3 years for hydraulics and 10 years for body parts

Pneumatic-hydraulic jack for heavy construction equipment with a high base

Description:

- Minimum height 425 mm
- Maximum height 725 mm with extensions up to 1025 mm
- Designed for heavy, heavy commercial use
- Solid chrome plated cylinder for durability
- Integrated safety relief valve
- Manual emergency control for optimum safety during lifting and lowering
- Supplied with 2 extensions (100/200 mm)
- Manufacturer: Denmark
- Warranty: 3 years

Technical parameters:

- Lifting capacity: 65 tonnes
- Minimum height: 425 mm
- Maximum height: 725 mm
- Body length: 980 mm
- Handle length: 1160 mm
- Width: 300 mm
- Width (with wheels): 390 mm
- Required compressed air pressure: 9 - 12 bar
- Required compressed air flow: 350 L / min
- Weight: 138 kg

Additional equipment:

- F250: extension, 250 mm
- FW: nozzle for bolting and so on.
- FW1: nozzle for lifting under various axles
