Pneumatic-hydraulic jack for high-base machines AC Hydraulic 25-1H


AC-Hydraulic, Denmark; Warranty: 3 years for hydraulics and 10 years for body parts

One-step, high lift pneumatic-hydraulic jack for agricultural, construction equipment, truck trailers and other high-foundation machines

Description:

- Minimum height of 360 mm
- Maximum height of 610 mm
- Solid chrome plated cylinder for durability
- Integrated safety relief valve
- Manual emergency control for optimum safety during lifting and lowering
- Supplied with two extensions (50/100 mm)
- Ergonomic handle with control buttons
- Warranty: 3 years

Technical parameters:

- Lifting capacity: 25 tonnes
- Minimum height: 360 mm
- Maximum height: 610 mm
- Body length: 820 mm
- Handle length: 1160 mm
- Width: 230 mm
- Width (with wheels): 310 mm
- Required compressed air pressure: 9 - 12 bar
- Required compressed air flow: 350 L / min
- Weight: 71 kg

Additional equipment:

- F250: extension, 250 mm
- FW: nozzle for bolting and so on.
- FW1: nozzle for lifting under various axles
