Name: Pneumatic-hydraulic jack AC Hydraulic 100-1L
Brand: AC-HYDRAULIC
SKU: 100-1L
Price: 8470.00 EUR
Availability: InStock

Pneumatic-hydraulic jack AC Hydraulic 100-1L

Pre-order

8,470.00€

Ex Tax: 7,000.00€

Prices include VAT

Qty

Add to Cart

Add to Wish List

Want to buy or learn more?

Pneumatic-hydraulic jack AC Hydraulic 100-1L

AC-Hydraulic, Denmark; Warranty: 3 years for hydraulics and 10 years for body parts

Description:

Industrial jack that is fully adapted to heavy machinery.

Heavy-duty construction made of steel.

Large tire wheels for easy positioning

The innovative design makes it possible to repair or replace wheels on site

Thanks to its balanced height, it is convenient to transport the jack even on uneven surfaces

Ergonomic handle with many positions

Guards ensure a safe lifting and lowering process

The safety valve prevents defects in the event of fluid leakage

Possibility of extensions and safety rings (optional)

Technical parameters:

- Lifting capacity: 100 tonnes

- Minimum height: 435 mm

- Maximum height: 570 mm

- Body length: 1550 mm

- Handle length: 1300 mm

- Width: 465 mm

- Required compressed air pressure: 10 bar

- Required compressed air flow: 1200 L / min

- Weight: 332 kg
