Plasma cutting machine 50A
Plasma cutting machine 50A
Plasma cutting machine 50A
Plasma cutting machine 50A
Plasma cutting machine 50A
Plasma cutting machine 50A
Plasma cutting machine 50A
Plasma cutting machine 50A
Plasma cutting machine 50A

Plasma cutting machine 50A

  • SKU: BD16622
641.30 €

Prices shown include tax

Send Message

Description

Plasma cutting machine 50A

Warranty: By registering your equipment at www.soldatech-welding.com, you can extend the warranty period up to 5 years.

The PL50HG cuts a variety of materials. There is a compact, powerful and easy-to-use plasma cutter with Pilot ARC pre-ignition. As a result, combined with HF ignition, this cutter ignites very easily and can cut through rusted, coated or textured material up to 20mm without any difficulty. The PL50HG has a convenient control panel and can even be adjusted during cutting to achieve the best cutting result. The advanced IGBT inverter technology not only ensures that the PL50HG works for a long time with higher power, but it is also lightweight and portable. Overload protection combined with a built-in fan prevents overheating and ensures high-quality welding performance for a long time. Ideal for cutting low alloy steel, stainless steel and aluminum alloys.

Standard equipment:
  • Soldatech PL80M5 plasma torch with 5m cable
  • Welding ground terminal with 2m 16mm² cable
  • 4m gas pipeline with hose clamps
  • Neoprene power cable 2m 3x2.5mm²
  • European Dinse connectors 9mm
Technical specifications:
  • Voltage = 230V – 1 phase
  • Frequency = 50/60Hz
  • Circuit breaker = 16A C-car
  • Input power = 7.6kVA
  • Duty cycle (at 20°C ambient temperature) = 60% - 50A
  • Duty cycle (at 40°C ambient temperature) = 20% - 50A
  • Welding current range = 15 - 50A
  • Max. no load voltage = 293V
  • Max. cutting thickness = 20 mm
  • Air consumption = 220L/min
  • Protection class = IP21S
  • Dimensions = 459 x 200 x 338 mm
  • Weight = 11kg
