Plasma cutter Hugong 125A PFC

Plasma Cutter Hugong 125A PFC

Country of origin: Netherlands, warranty period – 24 months

The Hugong INVERCUT125 plasma cutter is an extremely powerful industrial-grade cutting machine in the 125A class, designed for heavy-duty cutting applications. It features modern IGBT inverter technology, Pilot ARC HF ignition, and an integrated PFC system that ensures stable operation and low power grid load even under intensive use. With a maximum cutting thickness of up to 50 mm, it is an ideal solution for production and the metalworking industry.

A major advantage of this model is the CNC connection, allowing integration into automatic cutting machines or gantry-controlled systems. The unit is equipped with wheels for convenient transport within the workshop.

Suitable for cutting low-alloy steel, stainless steel, and aluminum alloys up to 50 mm thick.

Features:

• PFC module (Power Factor Correction): reduces electrical grid load and ensures stable performance even with voltage fluctuations
• CNC connection: allows connection to automated cutting systems and CNC tables – ideal for serial production
• Pilot ARC ignition with HF: enables contactless cutting through rust, paint, or coatings
• ABS shock-resistant housing: durable industrial-grade casing, designed for tough working environments

Technical Specifications:

• Frequency: 50/60 Hz
• Voltage: 400 V, 3 phase
• Input power: 20.8 kVA
• Start-up voltage: 340 V
• Cutting current range: 20 – 125 A
• Duty cycle (at 20°C): 100% at 125 A
• Duty cycle (at 40°C): 60% at 125 A
• Recommended cutting thickness: 25 mm
• Maximum cutting thickness: 35 mm
• Protection class: IP21S

Supplied with:

• LT141 plasma cutting torch – 5 m
• Ground clamp with 3 m cable (16 mm², 200 A)
• Quick couplings 10–25
• Gas hose Ø 8 mm – 3 m
• Hose clamps 10–16 mm (4 pcs)
• Pressure reducing valve – 1 pc

Product Dimensions:

• Length: 719 mm
• Width: 308 mm
• Height: 633 mm
• Weight: 56.0 kg

Packaging Dimensions:

• Length: 643 mm
• Width: 331 mm
• Height: 722 mm
• Weight: 59.00 kg
