  • SKU: BD70813
5,099.00 €

Prices shown include tax

Send Message

Description

Planer-thicknesser Holzmann HOB410PROSMW4_400V

Country of origin: Germany, warranty period - 24 months

The Holzmann HOB410PROSMW4 planer-thicknesser is high-quality industrial equipment designed for professional woodworking. The machine is equipped with a spiral cutter block featuring 68 inserts, two adjustable feed rollers, and a tiltable heavy-duty fence. The cast iron tables with ground surfaces ensure durability and precision, while the powerful motor allows efficient processing of even thick workpieces.

Functions:
  • High-quality industrial-grade equipment
  • Tables tilt backwards – do not obstruct in thicknessing mode
  • Cast iron tables with ground surface
  • Heavy-duty professional fence – tiltable from 90° to 45°
  • Two adjustable feed rollers for thicknessing
  • Spiral-toothed infeed roller facilitates easy feeding of the workpiece
  • Precisely mounted spiral cutter block with 68 inserts (4 grooves, 17 inserts each)
  • Thicknessing table with additional lateral support
  • Stable side-mounted fence with guide
  • Included: pre-installed cutter inserts (15 x 15 x 2.5 mm, 30°), professional fence, counter block
Technical specifications:
  • Planing table dimensions: 1800 x 410 mm
  • Thicknessing table dimensions: 700 x 410 mm
  • Thicknessing table height: 870 mm
  • Maximum thicknessing cutting depth: 5 mm
  • Maximum planing cutting depth: 4 mm
  • Maximum workpiece height: 230 mm
  • Planing fence dimensions: 1100 x 155 mm
  • Fence tilt: 90°–45°
  • Cutter block diameter: 98 mm
  • Cutter block speed: 4700 rpm
  • Feed speed: 7 m/min
  • Motor power (S6): 5500 W
  • Voltage: 400 V / 50 Hz
  • Dust extraction port diameter: Ø120 mm
  • Overall dimensions: 1800 x 470 x 1000 mm
  • Sound power level: 108 dB(A)
  • Sound pressure level: 79 dB(A)
  • Net weight: 420 kg
  • Gross weight: 495 kg
  • Packaging dimensions: 2000 x 845 x 1100 mm (L x W x H)
