Planer-thicknesser HOB260MINI_230V Holzmann

Planer-thicknesser HOB260MINI_230V Holzmann

Country of origin: Germany, warranty period - 24 months

The Holzmann HOB260MINI_230V planer-thicknesser is a compact and functional machine designed for woodworking tasks, both planing and thicknessing. With its sturdy grey cast iron table, reversible knives, and integrated mobility device, this machine is ideal for smaller workshops or projects that require precise and convenient material processing.

Functions:

• Compact design suitable for small workshops
• Easy switching between planing and thicknessing modes
• Sturdy grey cast iron thicknessing table
• Reversible planing knives for quick replacement
• Adjustable planing fence (90°–45°)
• Integrated mobility device
• Includes 2 reversible planing knives (260 x 18.6 x 1.2 mm)

Technical specifications:

• Planing table dimensions: 1040 x 260 mm
• Thicknessing table dimensions: 400 x 260 mm
• Maximum cutting depth: 3 mm
• Maximum thicknessing height: 160 mm
• Planing fence dimensions: 1100 x 150 mm
• Fence angle: 90°–45°
• Cutter block diameter: 63 mm
• Cutter block speed: 6500 rpm
• Number of knives: 2
• Feed speed: 5 m/min
• Motor power (S6): 2200 W
• Voltage: 230 V / 50 Hz
• Table height: 860 mm
• Dust extraction port diameter: 100 mm
• Sound power level: 102.1 / 99.1 dB(A)
• Sound pressure level: 95.6 / 91.5 dB(A)
• Gross weight: 79.50 kg
• Net weight: 72 kg
• Packaging dimensions: 710 x 570 x 590 mm
