Planer Holzmann AHM530P_400V

Planer Holzmann AHM530P_400V

Country of origin: Austria, warranty period - 24 months

The Holzmann AHM530P_400V planer is designed for heavy-duty industrial applications and features an extremely robust and ground working table. The conveniently positioned top control panel, large adjustment handwheel, and precise cutter block system ensure excellent planing results. Thanks to its high performance and accuracy, this machine is perfectly suited for intensive professional use.

Functions:

• Heavy-duty industrial construction with a ground working table
• Convenient top-mounted control panel
• Large adjustment handwheel for precise cutting depth settings
• Parallel table adjustment system
• Precisely mounted cutter block ensures high-quality processing
• Sturdy tiltable fence (from 45° to 90°), dimensions: 1500 x 155 mm
• Maximum chip removal depth up to 8 mm
• Included: control panel, planer knives

Technical specifications:

• Maximum cutting depth: 8 mm
• Planing fence dimensions: 1500 x 155 mm
• Fence tilt angle: 45°–90°
• Planing table dimensions: 2900 x 530 mm
• Infeed table length: 1625 mm
• Table height: 890 mm
• Motor power (S6): 7700 W
• Motor power (S1): 5500 W
• Voltage: 400 V
• Dust extraction port diameter: 160 mm
• Cutter block diameter: 125 mm
• Cutter block speed: 4700 rpm
• Number of knives: 4
• Net weight: 835 kg
• Gross weight: 1050 kg
• Packaging dimensions: 3000 x 1200 x 1250 mm (L x W x H)
