Mobile petrol air compressor ATMOS PB82E
Mobile petrol air compressor ATMOS PB82E

Mobile petrol air compressor ATMOS PB82E

  • SKU: BD10083
0.00 €

Prices shown include tax

Send Message

Description

Mobile petrol air compressor ATMOS PB82E

Manufacturer: Atmos, Czech Republic.

PB82E - light weight but full of power. This model meets all EU noise requirements imposed by various institutions. It is extremely compact and meets all the required standards. Manufacturers have managed to create a device that is not only quiet enough to comply with CE directives, but also the most compact in its class. PB82E capacity to supply: 1.4 m3 / min @ 6 bar; 1.1 m3 / min @ 10 bar; 0.7 m3 / min @ 14 bar air flow.

The Atmos PB82E is ideal for this job.

An air flow of 6 bar is far more than enough pressure to use a 25 kg Atmos purifier or blender.

The 10 bar version is ideal for small, sandblasting, ice or soda sanding jobs. Also a suitable option for tire fitting services. PU for painting.

It is extremely compact and fits in a car or minibus with a universal body. It weighs just 140 kg.

Technical data:

Compressor manufacturer: Rotorcomp / NK31.

Nominal capacity: 1.4 / 1.1 / 0.7 m3 / min.

Nominal pressure: 6/10/14 bar.

Safety pressure valve: 14.8 bar

Operating temperature: -10 ° C to + 40 ° C.

Cooling system: oil injection.

Oil capacity: 3 l.

Compressor speed with maximum load: 4125/2950/1900 rpm.

Maximum system temperature: 110 ° C.

Maximum oil system pressure: 14.8 bar.

Maximum oil consumption: 3 mg / m3.

Service valve 1 x G3 / 4 "

Engine: Briggs & Stratton 24 hp VN61

Fuel type: petrol.

Start system: e. starter.

Number of cylinders: 2 cylinders.

Working volume: 627 cm3.

Engine cooling type: air.

Engine oil capacity: 1.7 l.

Engine speed and full load: 2500 rpm.

Normal engine speed: 2500 rpm.

Rated power: 16.9 kW

Fuel tank capacity: 8.5 liters.

Additional accessories:

If you need to have dry air, it is possible to order an additional 12V plug (100.00 EUR with VAT) and an external dehumidifier (1210.00 EUR with VAT)
