Mobile air compressor Rotair VRK 16
Manufacturer Rotair (Italy)
Lightweight and versatile mobile compressors, with a petrol engine that is lightweight. High maneuverability and easy transportation. Full and smooth access to all parts required for maintenance. Reduced operating costs.
Compact technology, especially manoeuvrable
Easy to transport, lift and load
Excellent access to care
Reduced operating costs
Honda Stage V engine
Automatic pressure relief at the end of the cycle
Models for Europe, USA (EPA-CARB tested)
Compressor specifications:
Operating pressure: 6 bar 87 psi / 11 bar 160 psi / 13 bar 188 psi
Operating capacity: 1600 l / min 57 cfm / 1100 l / min 39 cfm / 950 l / min 34 cfm
Min. operating pressure: 5.5 bar 80 psi
Drive system air-cushion: Belt-drive XPZ
Compressor cooling: oil / air
Oil cooling capacity: 5 l
Exhaust temperature: 20 ° C / 68 ° F
Drain valves: 1 x 3/4 "
Noise level EEC no. 2000/14: <97 LWA
Battery power: 12V cc - 330A-45Ah
Fuel tank capacity: 15 l
Technical data:
Engine manufacturer: Honda
Engine model: GX 630
Cylinders: 4
Issue: Stage V
Volume: 690 cc
Aspiration: 2
Max. engine power @ 3600 RPM: 15.5 kW-20.8 HP
Max. engine speed: 3000 RPM
Min. engine speed: 2000 RPM
Cooling: Air
Lubrication: Oil
Min / Max. operating temperature: -10 ° C ›+ 50 ° C / 14 ° F› 122 ° F
Max. altitude: 1800 m a.s.l.
Dimensions: 1125 x 775 x 1015 mm
Weight: 230 kg
