Mobile 4-column wireless lift for extremely heavy-duty vehicles ST1175 Stertil-Koni

Mobile 4-Column Wireless Lift for Extremely Heavy-Duty Vehicles ST1175 Stertil-Koni

Country of origin: Netherlands, warranty period – 24 months

6-column version, wireless option price: 159999.00 EUR including VAT

The Stertil-Koni ST1175 is the most powerful mobile column lift in this series, designed specifically for lifting extremely heavy-duty vehicles and special structures such as containers. Each column boasts an impressive lifting capacity of 17,500 kg, making this model ideal for intensive use in industrial and military sectors. The unit features a robust construction and is equipped with an advanced eBright smart control system, ensuring precise and safe operation.

Features:

• Fixed-type forks – maximum reliability under extreme loads
• Ability to connect up to 32 columns in a single configuration
• Advanced eBright Smart Control system with a touch screen
• Synthetic wheels and hydraulic pallet truck-style mechanism for easy repositioning
• Retractable wheels reduce point pressure by a factor of 10 – minimizing the risk of floor damage
• Wireless models require charging only once every two weeks (via a 230 V wall socket)
• Cabled models operate on a 400 V power supply
• Extra durable drive-over cables and industrial-grade plugs (for cabled versions)
• Reliable hydraulic system with reduced friction – long-lasting and low-maintenance operation
• Manual lowering function in the event of a power outage
• Strict quality testing performed at the factory
• Maximum protection of the cylinder and seals against damage

Technical Specifications:

• Model: ST1175
• Lifting capacity: 17,500 kg (per column)
• Lift technology: hydraulic system with microprocessor-controlled synchronization
• Lifting height: 2,060 mm
• Lifting time: 215 seconds
• Motor power: 24 V, 130 A
• Weight: 1,385 kg
• Fork type: fixed
• Fork length: 450 mm
• Fork width: 806 mm

eBright Smart Control System

• Touch-sensitive screen enables simple and intuitive lift operation, real-time status monitoring, and precise control of the lifting and lowering process.

Retractable Wheels

• Facilitate easy repositioning of the lift within the workshop and reduce the risk of floor damage by minimizing pressure over a small surface area.

Reliable Hydraulic Technology

• Ensures smooth and long-lasting lift operation with minimal maintenance while providing maximum protection against damage.
