Metal lathe Holzmann ED1080ADIG
Metal lathe Holzmann ED1080ADIG

Metal lathe Holzmann ED1080ADIG

  • SKU: BD96617
10,549.99 €

Prices shown include tax

Send Message

Description

Metal lathe Holzmann ED1080ADIG

Manufacturer: Holzmann (Austria)

Features:

Ideal for use in sectors that require versatility, such as maintenance and production workshops, specialist workshops or for training purposes in schools

Extra wide shaft opening (Ø 52 mm) for machining large diameter metals

The foot brake ensures maximum work safety and reduces non-productive time

Induction-hardened and precision-ground prismatic guides made of stabilized cast iron for maximum lifetime accuracy

Cast iron machines that are characterized by extremely high stability

The removable bridge allows you to process workpieces with a diameter of up to 540 mm

Precision-cut gears and anti-vibration cast iron lathe pad ensure high rotational accuracy

Large digital display

Camlock D4 (ISO 702-2)

Complete set: 3-piece chuck Ø 200 mm, 4-piece chuck Ø 200 mm, front plate Ø 280 mm, 2x points MT4, feed cover, brake pedal, halogen work lamp, chip guard, cooling device (40W pump), stand with spindle brake , change gear, tools

Technical data:

Motor power s1: 2400 W

Power supply: 400V / 50Hz

Dimensions: 2080 x 810 x 1680 mm

Lathe width: 220 mm

Height of lathe: 310 mm

Distance between centers: 1080 mm

Center height: 200 mm

Max. position above the lathe bed: 400 mm

Max. turning of transverse turning: 250 mm

Max. gap: 540 mm

Turning speed min-1: 55-2000 (18)

Shaft bore: 52 mm

Shaft taper: MK6/MT6

Tailstock taper: MK4/MT4

Stroke: 750 mm

Cross slide travel: 195 mm

Compound slide stroke: 125 mm

Tailstock travel: 110 mm

Metric thread range mm/r: 0.4-7 (32)

Inch Thread Range: 4-60 TPI (36)

Max. tool holder cross-section: 20 x 15 mm

Longitudinal feed: 0.0527-1.2912 mm

Cross feed: 0.011-0.276 mm

Noise level: 78 dB

Net weight: 845 kg

Gross weight: 940 kg
