Key programmer ABRITES ZN003 PROTAG V2

Programming Equipment ABRITES ZN003 PROTAG V2

Functions:

• Key programming for Mercedes, BMW, VAG vehicles
• Support for Mercedes-Benz IR and truck keys
• Cloning of transponders and keys (Toyota, Hyundai, Ford, etc.)
• Resetting used OEM keys to "virgin" state
• Transponder production and configuration for new programming
• Operating mode configuration, authentication, and secret key programming functions
• EEPROM memory access and automatic transponder detection
• Remote control frequency reading (315, 433, 868, 915 MHz)
• Support for work with iOS/Android (via future Bluetooth expansion)

Main PROTAG 2.0 functions:

• Key programming for Mercedes, BMW, VAG vehicles
• Support for Mercedes-Benz infrared keys
• Support for Mercedes-Benz truck keys
• Transponder/key cloning for multiple manufacturers
• Low-level operations with transponders and keys
• Resetting used OEM keys to "virgin" state
• Programming by immobilizer system dump (including Mercedes IR keys FBS3)
• Production of transponders and keys for use with different immobilizer systems
• Remote control frequency reading

Spare key and All Keys Lost programming for Porsche models from 2010 via BCM dump:

• Panamera (970) 2010+
• Cayenne (92A) 2011+
• Boxster (981) 2012+
• Cayman (981) 2012+
• 911 (991) 2012+
• Macan 2014+

Key/transponder cloning support:

• All Toyota / Lexus / Scion DST-AES / Hitag AES keys (H type)
• All Toyota / Lexus / Scion Tiris DST+ keys (G type)
• All Hyundai / Kia Tiris DST+ keys
• All HITAG-2 keys (e.g., Mercedes-Benz / Dodge Sprinter, Iveco, Porsche, ...)
• All Megamos 13 keys (e.g., Volkswagen, Hyundai, Kia, ...)
• Megamos 48 keys (e.g., Chevrolet)
• All Temic 11/12 keys (e.g., Mercedes Sprinter, Mercedes Actros, ...)
• Ford / Mazda Temic 8C keys
• ID33 type keys (e.g., Opel, Peugeot, Renault, ...)
• All Tiris 4C keys (e.g., Ford, Honda, Acura, Toyota, ...)
• All Toyota / Lexus / Scion ID67, ID68, ID70 keys
• All Tiris 4D / 4E keys (e.g., Subaru, Ford, Mazda)

Low-level transponder operations:

• Read/write user data
• Read/write remote control data
• Operation mode configuration
• Authentication
• Secret key programming
• NVR (EEPROM) memory access
• Automatic transponder detection
• List of supported transponders/keys:
• Mercedes-Benz IR keys (FBS3)
• Mercedes-Benz truck keys
• All Philips PIT types – 7930, 7931, 7935, etc.
• All HITAG-2 (with EEPROM and remote control memory)
• All HITAG-Pro, HITAG-AES, HITAG-Extended, HITAG-3
• Audi BCM2 based keys
• Sokymat 8E with Audi EEPROM memory
• Megamos 13, emulated over T5/Nova, TK5551, PIT
• Megamos 48, Megamos AES
• Tiris 4C (cloning via TPX1)
• Tiris 4D/4E (cloning via TPX2/EH2/CN1/CN2/TA7/TA36)
• Tiris DST+ (cloning via TA68)
• Tiris AES (cloning via TA64)
• Temic 11/12 (cloning via T5/Nova or TK5551)
• Temic 8C (cloning via TK5551)

Reset OEM keys to factory state:

• Chrysler, Dodge, Jeep HITAG-2 keys
• Hyundai/Kia HITAG-2 keys
• Audi A6/Q7 keys
• All Toyota / Lexus / Scion smart keys

Remote control frequency reading:

• 315 MHz
• 433 MHz
• 868 MHz
• 915 MHz

Low-frequency transmitters LF 125 kHz:

• Read/program/authenticate
• All latest generation transponders from NXP® (HITAG-3, HITAG-Pro, HITAG-AES ...) and Texas® (DST-AES, CRAID-AES)

Radio Transceiver/Receiver/Analyzer:

• Operating in ISM/SRD bands: 300–348 MHz / 387–464 MHz / 779–928 MHz
• Supports: 2-FSK, 4-FSK, GFSK, MSK, OOK, flexible ASK shaping

Infrared Transmitter/Receiver/Analyzer:

• Compatible with Mercedes-Benz™ IR keys
• Supports Mercedes-Benz™ truck keys
• Fast key generation, blank key programming via IR
• Key details: status, ROM version, positions

Technical specifications:

• Dimensions: 135 × 82 × 33 mm
• Weight: 190 g
• Power: 5V DC
• Battery: 1100 mAh
• Consumption: 0.3 A
• Interfaces: USB Type-C
• Storage temperature: -20° to 70°C
• Storage humidity: 5% – 90%
• Operating temperature: 5° to 40°C
• Operating humidity: 15% – 70%

Set contents:

KT010 – Tag Key Tool

• Additional tool for working with key tags (transponders)

BASE SOFTWARE FOR PROTAG V2

• ZN003 – PROTAG Programmer v2 & TA31

PROTAG key and transponder programmer ZN003 (2nd generation) with TA31 module

More information available on the official ABRITES website
