ISCAN diagnostic tool for KAWASAKI motorcycles OBDSTAR

ISCAN Diagnostic Tool for KAWASAKI Motorcycles OBDSTAR

Country of origin: China, warranty period – 24 months

ISCAN KAWASAKI is a professional portable diagnostic tool specifically designed for KAWASAKI motorcycle diagnostics and key programming. This device operates on the Android 5.1.1 operating system, features a powerful RK3128 quad-core processor and a 5-inch capacitive touchscreen. With its compact size and user-friendly design, ISCAN is well-suited for workshop use, providing fast and reliable diagnostics for KAWASAKI vehicles.

Functions:

• Android 5.1.1 operating system
• Simple and intuitive menu navigation
• Complete diagnostic functionality: reading and clearing fault codes, data stream, activation tests, coding, settings
• Free menu selection allows quick access to needed functions
• Real-time data recording and playback for precise identification of sensor or component faults
• Wi-Fi connection with one-click software update
• Remote support via one-click function – OBDSTAR technician connection
• First fault guidance, technical bulletins, support data, and connector locations help quickly and accurately diagnose issues
• Multiple data display modes – text, waveform, and instrument panel simulation
• Automatic scanning, VIN recognition, control module programming, ECU settings, instrument coding
• TPMS, service light reset, CO and idle speed adjustment, A/F value reset, ABS, EOL, transmission and memory reset

Technical specifications:

• Operating system: Android 5.1.1
• Processor: RK3128 quad-core ARM Cortex-A7
• Battery: 2600 mAh rechargeable polymer lithium battery
• Memory: supports 32 GB micro SD (TF) card
• Display: 5.0-inch capacitive touchscreen
• Display resolution: 800 × 480
• Wi-Fi: supported
• Operating temperature: -20℃ ~ 55℃
• Storage temperature: -20℃ ~ 70℃
• Weight: approx. 700 g
• Dimensions: 198 mm × 115 mm × 31 mm

Included accessories for ISCAN KAWASAKI:

• M001A – Main cable
• M005 – KAWASAKI adapter
• M006 – KAWASAKI adapter
• N041 – OBD -6 adapter
• 12V2A – Charger
