Inverter battery charger GYS Flash 102-12 HF

Inverter Battery Charger GYS Flash 102-12 HF

Country of origin: France, warranty period - 24 months

The GYS Flash 102-12 HF is an extremely powerful inverter battery charger, specifically designed for wall or vehicle lift mounting. This device can deliver up to 100A of current and ensures a stable 12V battery voltage during diagnostic work. The GYS Flash 102-12 HF not only helps maintain the stability of a vehicle’s electrical system but also guarantees an efficient and safe battery charging process, adapted to the most advanced vehicle technologies.

Functions:

• Battery charging: Suitable for 12V lead-acid, AGM, and gel batteries (20–1200 Ah)
• Diag+ mode: Provides up to 100A of stabilized current for diagnostic operations
• Battery replacement: Maintains stable power supply to preserve vehicle memory settings during battery replacement
• Power supply: Adjustable voltage and current, tailored to the vehicle’s needs
• Showroom mode: Compensates for the voltage consumed by the vehicle, ensuring a continuous power supply
• Automatic reboot function: Saves settings and automatically reboots in case of a power failure
• Cable management and calibration: Supports up to 2x8 m – 16 mm² cables for flexible equipment use
• Showroom mode locking: Prevents accidental use, particularly useful in workshops and exhibitions
• Advanced charging curves: Includes an integrated "easy" mode for simplified charging, adaptable to all lead-acid batteries
• 9-step charging curve: Ensures maximum battery performance and longevity
• SOS automatic recovery: Can revive deeply discharged batteries (below 2V)
• Electronic protection: Short-circuit, polarity reversal, and overload protection with anti-spark technology
• Temperature sensor: Protects the internal electronics from overheating
• Automatic standby mode: Activates when the battery is disconnected
• Additional mounting options: Sliding or magnetic mounting systems available for secure equipment installation

Technical Specifications:

• Power supply: 220 – 240V AC / 1 phase / 50-60Hz
• Power output: 1600W
• Charging current: 100A
• Supported batteries: 12V
• Battery capacity: 20 – 1200 Ah
• Fuse: 125A
• Dimensions: 295 x 117 x 345 mm
• Weight: 5.8 kg
