High capacity pneumatic-hydraulic jack AC Hydraulic 100-1H
High capacity pneumatic-hydraulic jack AC Hydraulic 100-1H

High capacity pneumatic-hydraulic jack AC Hydraulic 100-1H

  • SKU: BD13690
10,406.00 €

Prices shown include tax

Send Message

Description

High capacity pneumatic-hydraulic jack AC Hydraulic 100-1H


AC-Hydraulic, Denmark; Warranty: 3 years for hydraulics and 10 years for body parts

High tonnage pneumatic-hydraulic jack for mining and construction industry

Description:

- Designed for outdoor maintenance in heavy tonnage heavy industrial equipment
- The construction is made entirely of solid steel to adapt to tough working environments
- Large rubber tires allow easy positioning on difficult surfaces
- Innovative chassis design simplifies jack maintenance and even changing wheels at the workplace
- High ground clearance for easy use in difficult areas
- Multi-position handle for easy tilt and optimum safety during lifting and lowering
- Safety valve prevents overload, jamming or other malfunctions caused by hydraulic fluid leakage
- Manual emergency control for optimum safety during lifting and lowering
- Manufacturer: Denmark
- Warranty: 3 years

Technical parameters:

- Lifting capacity: 100 tonnes
- Minimum height: 950 mm
- Maximum height: 1600 mm
- Case length: 1675 mm
- Handle length: 1300 mm
- Width with wheels: 685 mm
- Required compressed air pressure: 10 bar
- Required compressed air flow: 1200 L / min
- Weight: 546 kg
