You can order installation!
  • SKU: BD99707
0.00 €

Prices shown include tax

Send Message

Description

Four-column freight elevator with a network of 3-10m

The two-column freight elevator is widely used in warehouses and factories indoors and outdoors when it is desired to lift goods or pallets between different floors.

These, also called wall-mounted hoists, are suitable for lifting loads in small spaces. This allows you to lift your load to any floor comfortably, efficiently, conveniently and safely, as there are control panels on different floors, which will give you mobility.

All cargo lifts are manufactured according to special orders, according to technical needs. So you can choose the version that suits you best or which solution would be most comfortable in your existing premises. All the components made of the construction are of the highest quality, and the lift itself has all the necessary CE and ISO certificates.

Optional extras:
  • Steel sheet walls
  • Elevator closing blinds
  • The doors open
  • Fixed ramps to the elevator
  • Additional motor protection box
  • Fence around the elevator
  • Dual motors for faster lifting
  • The entire elevator is surrounded by medallion grilles
  • Electric lock
Modelis Keliamoji galia Platformos matmenys Maks. aukštis Pagrindo matmenys Bendri matmenys
LRL0,5-3 500kg 1,5 x 1,5 m 3m 350mm 2,4 x 1,8 x 5,5 m
LRL0,8–6 800kg 1,5 x 1,8 m 6m 350mm 2,4 x 2,1 x 8,5 m
LRL1,5–3,3 1500kg 2 x 2m 3,3 m 350mm 2,9 x 2,4 x 5,8 m
LRL5-8 5000 kg 3 x 2,8 m 8m 350mm 3,95 x 3,2 x 10,5m
LRL1-10 1000kg 1,8 x 2,3 m 10m 350mm 2,6 x 2,7 x 12,5 m
