Electro-hydraulic Self-propelled Stacker 1000 kg NH Handling SKS1229

Country of origin: Denmark, warranty period - 36 months

The NH Handling SKS1229 is a reliable and compact electro-hydraulic self-propelled stacker designed for efficient lifting and transportation of loads up to 1000 kg. It is ideal for use in warehouses and internal logistics. The unit features ergonomic controls, safety functions, and an integrated charger, ensuring smooth operation even in confined spaces.

Functions:

Can be operated via handles
Ergonomic arrangement of all control elements on the handle
PIN code panel for secure startup
Impulse speed control from slow to fast
Automatic braking when the handle is released
Reverse movement is disabled during lifting
Built-in charger (1 x 230 V / 24 V - 12 A)
Option to equip with an hour limiter

Technical specifications:

Lifting capacity: 1000 kg
Lifting function: electric hydraulic
Drive motor: Hangzhou
Battery: 2 x 12 V / 85 Ah
Lifting height: 2900 mm
Overall height: 3337 mm
Fork lifting height: 1930 mm
Travel speed without load: 4.6 / 4.2 km/h
Lifting speed without / with load: 19 / 12 mm/s
Maximum incline without / with load: 10 / 5˚
Fork width: 570 mm
Fork wheels: Ø 84 x 93 mm
Steering / drive wheels: Ø 210 x 70 mm
Support wheels (adjustable): Ø 100 x 60 mm
Weight: 594 kg
