Electro-hydraulic press 50-Ton
Electro-hydraulic press 50-Ton
New

Electro-hydraulic press 50-Ton

  • SKU: BD70470
1,850.00 €

Prices shown include tax

Send Message

Description

Electro-hydraulic Press 50-Ton

Country of origin: China, warranty period - 24 months

This 50-ton electrohydraulic press is designed for industrial machinery production and assembly of spare parts. It is used for pressing, assembling, riveting, or forming metal components in production processes. The press is not intended for other uses. Its robust construction ensures reliable performance even under intensive workloads, making it ideal for mechanical workshops or production lines.

Features:
  • Powerful 50-ton pressing force
  • 1.5 kW motor power
  • Convenient working range from 88 to 1068 mm
  • Compact design that takes up minimal space
  • Sturdy bed (inner width 730 mm) for working with various part sizes
  • Suitable for assembly, pressing, and riveting of components
  • Simple operation and maintenance
  • Suitable for use at altitudes up to 1000 meters
  • Resistant to dust, non-aggressive, and non-flammable environments
Technical specifications:
  • Pressing force: 50 tons
  • Stroke: 220 mm
  • Voltage: 380V
  • Motor power: 1.5 kW
  • Input power: 3–3.5 KVA
  • Working range: 88–1068 mm
  • Bed size (inner width): 730 mm
  • Main body dimensions: 988 × 315 × 2020 mm
  • Product size: 1030 × 1918 × 740 mm
  • Net weight: 265 kg
  • Gross weight: 310 kg
  • Packing size: 965 × 330 × 2040 mm
  • Operating temperature: -5 ℃ to +40 ℃
  • Storage temperature: -25 ℃ to +55 ℃
  • Shipping temperature: -25 ℃ to +70 ℃ (not exceeding 24 hours)
  • Humidity: Max. 85% relative humidity at 40 ℃ (non-condensing)
  • Ambient light: >300 LUX
  • Atmosphere: Non-flammable, non-corrosive, and dust-free
  • Operating altitude: Up to 1000 meters
