Electric drilling / tapping machine Valkenpower M3 - M16

Electric drilling / tapping machine Valkenpower M3 - M16

This Cowley electric drilling / tapping machine is used for fast and accurate threading and drilling of various types of materials. The machine can be used both horizontally and vertically. The speed is variable and adjustable, the cooling is nicely integrated into the housing, and the machine has internal memory to store multiple programs.

The threading / drilling machine also has the following functions:

HD touch screen for easy operation in Dutch, English and French

PLC control

Self-lubricating bronze bushings ensure optimum flexibility

Wide range of threads from M3 to M16

Dynamically adjustable thread depth

Integrated on / off button

Weightless operation due to gas springs

Powerful servo motor

Electrically adjustable torque

Adjustable input and output speed

Touch screen with protective cover

Interchangeable thread heads with quick release system

Technical specifications:

power = 0.6kW

voltage = 230V

duty cycle = 100%

tapping range = M3 to M16

max. speed = 312 rpm

max. working radius = 1100 mm

The device is equipped with:

6x GT12 DIN thread holder with slip sleeve (adjustable torque):

M3 (ø 3.5 mm / stem = 2.7 mm)

M4 (ø 4.5 mm / stem = 3.4 mm)

M5 (ø6.0 mm / stem = 4.9 mm)

M8 (ø8.0 mm / stem = 6.2 mm)

M10 (ø10.0 mm / stem = 8.0 mm)

M12 (ø9.0 mm / stem = 7.0 mm)

2x GT12 DIN thread holder:

M14 (ø11.0 mm / stem = 9.0 mm)

M16 (ø12.0 mm / stem = 9.0 mm)

NOTE: The threaded lever is supplied without a mobile base cabinet with a cast iron top.
