Diagnostic tool JalTest PC Link 29365

Diagnostic tool JalTest PC Link 29365

Overview

Communication Interface that, along with Jaltest Software, connects your PC to the electronic control units installed on the vehicles

• It allows to connect via Bluetooth and using the USB cable.
• Integrated Bluetooth connection with transmission capacity up to 50m
• Rugged design
• Certifications:
• FCC
• CE
• RoHs

General information

• Operating supply voltage 8 V DC — 28 V DC
• Power consumption of vehicle's battery 7 watts
• Dimensions (length x width x height) 183.5 x 131.3 x 55.7 mm
• Weight (without cables) 1.217 kg
• Service temperature 0 °C – 40 °C
• Relative air humidity 90 % (at 25 °C)

Communication protocols (ISO 15031)

• ISO 9141-2
• SAE J1850 VPW
• SAE J1850 PWM
• SAE J1708
• SAE J2534
• SCI Haldex
• CAN ISO 11898, ISO 15765-4 (OBD)
• CAN Single Wire
• CAN Low Speed
• RP1210
• PASS THRU
