Commercial analyser for boilers and heat pumps KANE958

Commercial Analyser for Boilers and Heat Pumps KANE958

Country of origin: United Kingdom, warranty period - 24 months

The KANE958 is an advanced commercial analyser for boilers and heat pumps, suitable for systems up to 5 MW capacity and flue draughts up to 50 mbar. The device measures combustion efficiency, performs structured tightness and flue draught tests, and analyses indoor air quality. It features integrated KANE LINK wireless connectivity, enabling data transfer to the KANE LIVE app, while a hydrophobic filter protects sensors from moisture. With the ability to measure additional toxic gases such as NO, NO₂, and SO₂, this analyser is designed for both industrial and marine boiler applications.

Functions:

• Designed for commercial, industrial, and marine boilers up to 5 MW capacity
• Measures combustion efficiency, excess air, and CO₂ concentration
• Structured tightness, let-by, and flue draught tests
• Temperature measurements for heat pumps and boilers
• Wireless KANE LINK connectivity for data transfer to the KANE LIVE app
• CO migration, temperature, humidity, and airflow analysis in indoor environments
• Hydrophobic filter prevents sensor damage from moisture
• Hydrogen (H₂) ready – supports up to 20% H₂ concentration
• Infrared interface for printing results with the optional KANE-IRP3 printer
• Easy operation with a large display and rotary dial

Technical Specifications:

• Measurements:
• O₂: 0–21%
• CO: 0–10,000 ppm with H₂ compensation and overload protection (optional up to 100,000 ppm / 10%)
• Optional additional gas measurements:
• NO: 0–5,000 ppm
• NO₂: 0–1,000 ppm
• SO₂: 0–5,000 ppm
• Differential temperature: -20 to +135°C
• Differential pressure: ±160 mbar
• Calculated Values:
• CO₂ concentration
• CO/CO₂ ratio
• NOx concentration (optional)
• Excess air
• Combustion efficiency
• Compatible Fuel Types:
• 10 standard fuels, including natural gas, LPG, butane, propane, light oil, heavy oil, and user-defined fuels

Box Contents:

• KANE958 analyser
• Probe
• USB charger
• Quick reference guide and analyser calibration certificate
