Chip extractor with 3 connection ports for workshops

Chip Extractor with 3 Connection Ports for Workshops

Country of origin: Germany, warranty period – 24 months

This powerful chip extraction unit is a professional solution for the efficient removal of dust and wood chips in workshops, allowing simultaneous connection of up to three machines. Its robust construction, efficient motor, and large filter surface ensure consistently high suction performance even during extended use. Equipped with four swivel casters, the unit can be easily moved wherever needed within the workshop.

Features:

• Solid blower wheel housing – for long-lasting durability and stability
• Reliable dust collection system – designed for intensive use
• Powerful 1500 W motor and intelligent airflow design
• Consistent high-performance suction for continuous duty
• Allows connection of three machines simultaneously using a distributor piece
• Large filter surface (Ø500 mm / 1100 mm) – for more efficient dust removal
• Four swivel casters – for full mobility in the workshop

Technical Specifications:

• Motor Data:
• Motor power (S1): 1500 W
• Voltage: 230 V / 50 Hz
• Cable length: 1.8 m
• Speed: 2950 min⁻¹
• Dimensions:
• Overall dimensions: 985 x 560 x 2450 mm
• Dust Extraction:
• Suction performance: 3000 m³/h
• Chip bag diameter: 500 mm
• Chip bag length: 850 mm
• Fan wheel diameter: 300 mm
• Negative pressure: 2200 Pa
• Connections: 3 x Ø100 mm
• Noise and Vibration:
• Sound pressure level: <85 dB(A)
• Weight:
• Net weight: 45 kg
• Gross weight: 48 kg

Packaging:

• Packaging length: 1050 mm
• Packaging width: 595 mm
• Packaging height: 505 mm
