Blasting booth set PS PAL4-XL Sabbiatrici

Blasting booth set PS PAL4-XL Sabbiatrici

Country of origin: Italy, warranty period - 24 months

Possible additional modifications and various accessories are available upon request

The PS PAL4-XL vacuum-type blasting and shot peening booth is intended for professional surface treatment in industry, restoration, and maintenance sectors. It allows for shot peening, decorative sandblasting, metal hardening, cleaning, deburring, and other surface preparation operations. By using different abrasives – from corundum to glass microspheres or metal granules – the process can be precisely adapted to different materials. The booth can be optionally equipped with a dust filter system, loading cart, rotary table, or abrasive regeneration cyclone. If necessary, it can be converted into a pressure-type system, enabling even faster and more accurate surface processing.

Functions:

• Suitable for shot peening, sandblasting, metal hardening, cleaning, and surface preparation
• Compatible with various abrasives: corundum, sand, glass microspheres, metal or vegetable granules
• Convertible to a pressure system
• Optional accessories: dust collection filter, loading cart, rotary table, regeneration cyclone
• Suitable for working with aluminum, iron, glass, stainless steel, etc.
• Enables deep engraving or light surface polishing

Technical specifications:

Internal dimensions:

• Front – 1440 mm
• Side – 1090 mm
• Height – 800 mm

External dimensions:

• Front – 1480 mm
• Side – 1600 mm
• Height – 1900 mm

Booth access: side, from both left and right

• Dust extractor: 400 V, 50 Hz, 0.75 kW
• Lighting: LED 20 W

Air consumption:

• Injector ∅ 3 mm – 600 l/min
• Injector ∅ 3.5 mm – 800 l/min
• Injector ∅ 4 mm – 1200 l/min
• Operating pressure: from 1.5 to 8 bar
• Tungsten carbide nozzle: ∅ 6, 8, or 10 mm
• Weight: 300 kg

Set includes:

• Blasting booth PS PAL4-XL
• Wear-resistant rubber lining
• Pressure tank (24 L)
• Dust collection filter with self-cleaning compressed air system
