Battery charger - starter 12/24V GYS STARTIUM 330E

Battery Charger - Starter 12/24V GYS STARTIUM 330E

Functions:

• Automatic battery charging – A multi-stage process that fully charges the battery to 100% without requiring removal from the vehicle.
• Floating mode – Maintains a 100% charge at the end of the charging process.
• Intelligent system – Automatically analyzes the battery condition and adjusts the voltage while displaying charge information on a digital screen.
• Vehicle electronics protection – Prevents sparking, and voltage is only supplied when connected to the battery.
• SOS Recovery function – Restores sulfated batteries.
• Deeply discharged battery charging – Can charge batteries discharged down to 1V (if not damaged).
• Automatic start – When the starter function is activated, the device automatically supplies current.
• Smart start – If a damaged or heavily compressed battery is detected, the device will not supply current, protecting the vehicle's electronics.
• Fault diagnostics – The digital screen displays fault codes, while the alternator testing function helps identify electrical system faults.
• Timer function – Ensures safe charging of deeply discharged batteries (<1V).

Technical Specifications:

• Power supply voltage: 230V, 50/60 Hz
• Current: 16A
• Power: 800W
• Battery voltage: 12V or 24V
• Battery capacity:
• 12V: 20–375Ah
• 24V: 20–300Ah
• Modes: 4 starting modes
• Adjustable current:
• 12V: 5–10–15–25A
• 24V: 5–10–15–20A
• Maximum current:
• 12V: 165A
• 24V: 130A
• Fuse: 200A
• Protection rating: IP21
• Dimensions: 425 x 255 x 255 mm
• Weight: 15 kg
