Band metal cutting machine Holzmann BS712TURN-G 400V

Band metal cutting machine Holzmann BS712TURN-G 400V

Manufacturer: Holzmann (Austria)

Features:

Metal band saw with gearbox for adjusting the speed of the band (3 steps)

Space-saving machine thanks to the rotating cutting arm

Automatic stop

The sturdy machine is made of cast iron

With chip drainer and coolant pump and tank (25W, 10l)

The descent speed is continuously adjustable via a hydraulic cylinder

Rotating professional lever and workpiece limiter

Complete set: machine tool (2630 x 20 x 0.9 mm), moving device, workpiece limiter

Technical data:

Motor power s1: 1100V

Voltage: 400V / 50Hz

Dimensions: 1250 x 985 x 910

Cutting efficiency round metal Ø -45°: 150 mm

Cutting efficiency round metal Ø 45°: 140 mm

Cutting efficiency round metal Ø 90°: 205 mm

Cutting efficiency square metal -45°: 100 x 200 mm

Cutting efficiency square metal 45°: 140 x 90 mm

Cutting efficiency square metal 90°: 215 x 205 mm

Saw band: 2360 x 20 x 0.9 mm

Noise level: 82.8 dB

Saw blade speed: 39/55/67 m/min

Weight: 181 kg

Total weight: 201 kg

Package dimensions: 575 x 1260 x 1145 mm
