Band metal cutting machine Holzmann BS320TOP 400V
Band metal cutting machine Holzmann BS320TOP 400V

Band metal cutting machine Holzmann BS320TOP 400V

  • SKU: BD96799
3,872.00 €

Prices shown include tax

Send Message

Description

Band Metal Cutting Machine Holzmann BS320TOP 400V
Country of origin: Austria, warranty period - 24 months

The Holzmann BS320TOP 400V is a highly durable, professional-grade band metal cutting machine designed for precise cutting operations across various metalworking processes. With its robust construction, powerful two-speed transmission, and adjustable saw frame, this machine ensures the highest level of work efficiency. The combination of automatic and manual lowering functions, as well as the integrated cooling system, enables safe and convenient cutting operations.

Features:
  • Precise and durable metal construction ensures reliable performance.
  • Powerful two-speed transmission allows for optimal work speed selection.
  • Cutting angle adjustment: left from 0° to 45°, right from 0° to 60°.
  • The saw arm can be lowered automatically or manually.
  • Automatic shut-off with limit switch after cutting is completed.
  • Sturdy vise with a convenient working height (950 mm from the floor).
  • Hydraulic cylinder allows continuous adjustment of lowering speed.
  • Two-speed saw blade speed selector (35 m/min or 70 m/min).
  • Pressure gauge for precise monitoring of saw blade tension.
  • Integrated machine stand with doors, shelf, 15-liter coolant tank, and 45 W coolant pump.
  • Included accessories: saw blade (2680 x 27 x 0.9 mm), CEE plug.
Technical specifications:
  • Motor power (S1 mode): 1100 / 1500 W
  • Voltage: 400V / 50Hz
  • Dimensions: 2000 x 1500 x 1900 mm
  • Cutting capacity (round metal) at -45°: 190 mm
  • Cutting capacity (round metal) at 45°: 190 mm
  • Cutting capacity (round metal) at 60°: 140 mm
  • Cutting capacity (round metal) at 90°: 245 mm
  • Cutting capacity (square metal) at -45°: 200 x 140 mm (or 155 x 155 mm)
  • Cutting capacity (square metal) at 45°: 180 x 140 mm (or 155 x 155 mm)
  • Cutting capacity (square metal) at 60°: 140 x 125 mm
  • Cutting capacity (square metal) at 90°: 320 x 195 mm (or 245 x 245 mm)
  • Saw blade dimensions: 2680 x 27 x 0.9 mm
  • Saw blade speed: 35/70 m/min
  • Machine weight: 320 kg
  • Total weight with packaging: 384 kg
  • Packaging dimensions: 805 x 1600 x 955 mm
