Automatic key blade cutting equipment Xhorse Condor XC-Mini Plus

Automatic key blade cutting equipment Xhorse Condor XC-Mini Plus

Manufacturer MAGICMOTORSPORT (Italy), warranty 24 months.

The Xhorse Condor XC-Mini Plus key blade cutting equipment has a state-of-the-art design and the best features. This key cutting equipment can be used through the APP applet. Every day, by logging in through VVDI MB and you, the VVDI MB tool, you can get 1 free passkey every day. You can update the machine software online for free using the Xhorse Update Kit software. These machines have the latest version: V3.1.3. Supports more than 60 car brands from around the world and 2,000 car models. Integrated database of all major key loss! These machines have the most supported languages: English, Russian, Italian, Chinese, Portuguese, Spanish, French, German, Czech, Arabic, Turkish, Dutch, Polish, Bulgarian, Norwegian and Slovak.

What's updated in the latest Condor Mini Plus?

The gap between the cover and the key is larger than the XC-MINI. The XC-MINI has many keys with housings, such as: The VW flap key will not allow the lid to be closed, and the CONDOR XC-MINI Plus does not have this problem.

The screen is designed with an adjustable angle. Much more convenient to control and see what is on the screen.

Mounting supports - no vibration on any surfaces.

With better PCBs and motors, high quality to operate more stable and accurate.

Milling dust is much easier to remove - cutting the key will prevent dust from entering the machine, which will extend the life of the XC-MINI PLUS.

Key features:

The Condor XC-Mini automatic key cutting machine camp has two clamps M1 and M2 that support side, track, pit and tibble keys, some Dimble / Tibble keys require M3 clips used for Ford FO21 and CItroen SX9 keys.

Built-in database, detailed parameters, schematic sample depth key tool available to users, database based on empty key data, edit key shape, space area, depth to create new master data. It makes sense to synchronize the new master data with the machine.

The Condor XC-Mini Plus has a Appearance Patent Certificate, a Computer Software Copyright Registration Certificate, an Untility Model Patent Certificate, and more.

The Condor Mini Plus has three powerful features for all lost key databases

Aluminum main body, partly made of 304 code stainless steel materials. Net weight 18kg, so you can easily transport the machine with a comfortable handle.

The machine uses a 3-axle spare ball screw transmission with greater accuracy and stability than T-screw transmissions.

Xhorse Mini Condor specifications:

Operating temperature: 0-50

Operating voltage: 90-264V / AC

Input frequency: 47-63 Hz

Dimensions: 265x362x301 mm

Weight: 18kg

Total weight: 22.9 kg

Power: 200W

USB ports: 2.0

LCD screen: 1024x600

Engine speed: 9000 rpm

Additional accessories:

M3 clamp for Ford FO21 and Citroen SX9 keys

M4 clip for house keys

Power adapter with built-in battery

Milling cutter for 1.0 mm marking

1.5 mm cutter

2.0 mm cutter

2.5 mm cutter
