Aluminum wheelchair lift

Aluminum wheelchair lift

Country of origin: China, warranty period – 24 months

The aluminum wheelchair lift is designed for the safe and convenient movement of people with mobility impairments and elderly individuals between different height levels. The device solves accessibility issues in locations where installing a traditional elevator is impossible or inefficient. A robust structure, quiet operation, and advanced safety systems ensure reliable daily use in both private homes and public buildings.

Technical specifications:

• Maximum platform lifting height: from 1000 mm to 6000 mm
• Maximum load capacity: 250 kg
• Platform dimensions: 1430 x 1000 mm
• Minimum height: 60 mm
• Lifting speed: 0.06–0.1 m/s
• Control voltage: 24 V DC
• Input power: 1.1–2.2 kW
• Power supply: single-phase or three-phase
• Control system: hydraulic power unit with electric motor
• Operating environment: indoor and outdoor use, –20 °C to +70 °C
• Door configuration: 90° and 180°
• Installation: floor-mounted or wall-mounted
• Control: remote control possible up to 20 m distance

The aluminum wheelchair lift is a reliable and safe device designed for long-term use in real operating conditions. It ensures smooth, quiet, and comfortable movement between levels, contributing to an accessible environment for people with mobility impairments.
