4-post platform lift for heavy-duty vehicles ST 4250 Stertil-Koni

4-Post Platform Lift for Heavy-Duty Vehicles ST 4250 Stertil-Koni

Country of origin: Netherlands, warranty period – 24 months

Available Versions:

ST4250 ebright, platform length 7,200 mm (including standard drive-on ramps and end stops)

ST4250 ebright, platform length 8,200 mm (including standard drive-on ramps and end stops)

ST4250 ebright, platform length 9,200 mm (including standard drive-on ramps and end stops)

ST4250 ebright, platform length 10,200 mm (including standard drive-on ramps and end stops)

ST4250 ebright, platform length 11,700 mm (including standard drive-on ramps and end stops)

The ST 4250 is a highly powerful 4-post hydraulic vehicle lift designed specifically for extremely heavy vehicles such as trucks, buses, or specialized machinery. It features an impressive lifting capacity of 25,000 kg and platform lengths ranging from 6 to 11.5 meters. The lift’s unique crossbeam-free construction ensures maximum working height beneath the platforms and superior access. It also supports a tandem configuration with two connected lifts, making it ideal for extra-long vehicles.

Features:

• Extra-high lifting capacity – 25,000 kg: Ideal for extremely heavy vehicles and specialized equipment
• Platform lengths from 6 to 11.5 meters: Easily adaptable for various vehicle sizes
• Tandem compatibility: Allows for two-lift operation to handle the longest vehicle types
• Crossbeam-free construction between platforms: Adjustable installation width and improved accessibility
• Ebright Smart Control System: 7-inch color touchscreen with configurable settings and synchronized control of multiple lifts
• Mechanical gravity safety lock: Operates independently from the lifting system and remains constantly active
• Hydraulic safety system: Oil flow control and overload protection valves in each cylinder
• Automatic LED lighting: Impact-resistant lighting turns on above floor level for better visibility
• Programmable lifting height: Pre-set the desired lifting height for repeatable precision
• Durable design: Free of wear-prone parts such as ropes or pulleys, resulting in reduced maintenance needs and lower operational costs

Technical Specifications:

• Model: ST 4250
• Lifting system: Hydraulic
• Lifting capacity: 25,000 kg
• Lifting height: 1,900 mm
• Lifting time: 72 seconds
• Drive-on height: 285 mm
• Available platform lengths: 6 / 8 / 9 / 10 / 11.5 meters

Crossbeam-Free Construction

• The lift’s design without crossbeams between columns provides maximum space under the platforms and allows for optimal adjustment of the installation width. This significantly improves access to the lifted vehicle and increases overall workshop flexibility.

Ebright Smart Control System

• The advanced 7-inch color touchscreen control system enables intuitive and precise operation of the entire lifting process. Users can customize settings to meet specific requirements, with all vital information displayed clearly on one screen – improving safety and efficiency.

Automatic LED Lighting

• Shock-resistant LED lighting switches on and off automatically when the platform rises above floor level. This ensures excellent visibility underneath the vehicle without the need for additional lighting equipment.

Easy Accessibility

• The low drive-on height and open-frame design provide convenient access even for low-clearance vehicles. Perfect for both small and large workshops – saving both time and valuable floor space.
