4-post platform lift for heavy-duty vehicles ST 4175 Stertil-Koni

4-Post Platform Lift for Heavy-Duty Vehicles ST 4175 Stertil-Koni

Country of origin: Netherlands, warranty period – 24 months

Available Versions:

ST4175 ebright, platform length 8,200 mm (including standard drive-on ramps and end stops)

ST4175 ebright, platform length 9,200 mm (including standard drive-on ramps and end stops)

ST4175 ebright, platform length 10,200 mm (including standard drive-on ramps and end stops)

ST4175 ebright, platform length 11,700 mm (including standard drive-on ramps and end stops)

The ST 4175 is a highly powerful 4-post hydraulic vehicle lift designed for the most demanding tasks – from trucks to articulated vehicles or special machinery. This model offers a lifting capacity of 17,500 kg, platform lengths up to 11.5 meters, and can be used in a tandem configuration with two connected lifts. The ST 4175 has no upper crossbeam connections, providing maximum under-platform space and highly flexible installation width. It is ideally suited for low-clearance vehicles.

Features:

• High lifting capacity – 17,500 kg: Suitable for very heavy vehicles and specialized equipment.
• Platform lengths up to 11.5 m: Ideal for a wide variety of vehicle lengths – from trucks to buses.
• Tandem configuration: Option to connect two lifts for extremely long vehicles (e.g., articulated trucks).
• Ebright Smart Control System: 7-inch full-color touchscreen with user-configurable settings and the ability to control multiple lifts simultaneously.
• Mechanical safety lock: Patented gravity-based system operates independently of the lifting mechanism and remains continuously active.
• Hydraulic safety system: Each cylinder is equipped with an oil flow control valve and overload protection.
• Flexible installation width: Absence of top connecting parts allows the width to be adjusted according to workshop needs.
• LED lighting and programmable lift height: Shock-resistant LED lights automatically switch on above floor level; lifting height can be preset.
• Durable, low-maintenance design: No wear-sensitive parts like ropes or pulleys – ensures longevity and reduced operating costs.

Technical Specifications:

• Model: ST 4175
• Lifting system: Hydraulic
• Lifting capacity: 17,500 kg
• Lifting height: 1,900 mm
• Lifting time: 72 seconds
• Drive-on height: 230 mm
• Available platform lengths: 6 / 8 / 9 / 10 / 11.5 meters

No Upper Crossbeam Connections

• The lift’s design excludes any top crossbeam connections between posts, ensuring maximum space beneath the platforms and allowing for optimal installation width adjustment. This significantly improves access to the raised vehicle and provides greater flexibility in the workshop.

Ebright Smart Control System

• The advanced 7-inch full-color display enables intuitive and precise control over the entire lifting process. Users can easily configure settings according to their needs, with all essential information displayed clearly on one screen – improving safety and operational efficiency.

Automatic LED Lighting

• Impact-resistant LED lights are integrated into the lift and automatically switch on and off when the platform rises above floor level. This ensures optimal visibility under the vehicle without needing extra lighting equipment.

Easy Accessibility

• Low drive-on height and open-frame design ensure convenient access even for low-clearance vehicles. Ideal for both small and large workshops – saving both space and time.
