4-in-1 MIG/MAG welding machine Hugong NVM200HF

4-in-1 MIG/MAG Welding Machine Hugong NVM200HF

Country of origin: Netherlands, warranty period – 24 months

The Hugong NVM200HF is an advanced and versatile 4-in-1 welding inverter from the NOVI series, designed for professional use both in workshops and in the field. This device combines MIG/MAG, HF-TIG (high-frequency), Lift-TIG, and MMA (stick) welding, making it an excellent choice for welders who value flexibility, precision, and reliability.

Thanks to HF-TIG ignition (over 99% ignition success rate), TIG welding is extremely precise and reliable, even when working with thin materials or executing intricate welds. The integrated synergic control system automatically selects optimal parameters based on the material, wire type, and shielding gas. Additionally, PFC (Power Factor Correction) technology allows the machine to operate stably even with voltage fluctuations between 95 and 275 V – particularly useful when working with long extension cables.

Features:

• 4-in-1 welding capability: MIG, HF-TIG, Lift-TIG, and MMA in one machine
• Over 99% HF-TIG ignition success – stable arc from the first strike
• HDVision display with synergic control – intuitive operation and automatic parameter selection
• PFC technology – operates from 95 V to 275 V, ideal for use with extension cords
• Impact-resistant ABS housing – built for durability even in harsh conditions

Technical Specifications:

• Power supply: 230 V – single phase
• Frequency: 50/60 Hz
• Open-circuit voltage: 69 V
• Nominal input current: 36 A
• Duty cycle @20 °C: 40% – 200 A
• Duty cycle @40 °C: 20% – 200 A
• Welding Current Range:
• MIG: 40–200 A
• MMA: 10–180 A
• TIG: 10–180 A
• Compatible Welding Wire:
• MIG wire: 0.8 / 1.0 mm
• Protection class: IP21S

Product Dimensions:

• Length: 532 mm
• Width: 245 mm
• Height: 382 mm
• Weight: 15.2 kg

Packaging Dimensions:

• Length: 555 mm
• Width: 305 mm
• Height: 420 mm
• Weight: 17.80 kg

Included in the Package:

• MIG torch EP1500 – 3 m
• Ground clamp with 3 m cable (16 mm², 35–70 mm² quick connector)
• Gas hose – 4 m with NW5 coupling
• Wire spools: 0.8 mm and 1.0 mm (2 pcs each)
• Contact tips: 0.6 mm, 0.9 mm, 1.0 mm (1 pc each)
• Hose clamp 10–16 mm
