2-post lift for commercial vehicles FREEDOMLIFT SK 2090 Stertil-Koni

2-Post Lift for Commercial Vehicles FREEDOMLIFT SK 2090 Stertil-Koni

Country of origin: Netherlands, warranty period – 24 months

Available versions:

SK2090-23 with 2 single telescopic and 2 double telescopic arms

SK2090-33 with 4 double telescopic arms

The FREEDOMLIFT SK 2090 is the highest lifting capacity 2-post electro-hydraulic lift in the FREEDOMLIFT series, designed for larger motorhomes, heavier commercial vans, and small trucks. Its baseless construction, strong telescopic arms, and advanced safety solutions ensure safe, reliable, and flexible operation in any professional workshop.

Features:

• Highest lifting capacity in the FREEDOMLIFT series – up to 9,000 kg
• Two arm types available – choose between single or double telescopic lifting arms depending on your operational needs
• Baseless construction – no overhead connection, allowing easy access around the entire vehicle
• Automatic arm locking – the locking system activates automatically when the vehicle is lifted; arm adjustment is made easily using handles without the need for tools
• Proven durability – the hydraulic system has been tested for more than 20,000 lift/lower cycles under maximum load
• Mechanical safety lock – gravity-activated, engaging from a height of 210 mm, with locking increments every 35 mm
• Overload protection – built-in automatic overload safeguard and lift height limiter ensure extra safety
• Ergonomic controls – convenient control panel with hold-to-run buttons and the option to connect LED lighting
• Certified to international standards – CE (Europe), ANSI/ALI-ALCTV (USA), CSA (Canada)

Technical Specifications:

• Model: SK 2090
• Lifting capacity: 9,000 kg
• Lifting height: 1,980 – 1,955 mm
• Pick-up height: 130 – 145 mm
• Min. single telescopic arm length: 970 mm
• Max. single telescopic arm length: 1,610 mm
• Min. double telescopic arm length: 900 mm
• Max. double telescopic arm length: 1,940 mm
• Lifting time: 58 s
• Mechanical lock activation height: from 210 mm
• Locking increments: every 35 mm

Flexible Extended Arm Joints (EFA)

• Provide maximum lifting position flexibility. With hinged joints and multiple telescopic segments, this system is ideal for both passenger vehicles and longer commercial vans or minibuses.

Sliding Block System

• Ensures stable and smooth post operation. This system reduces friction between moving parts, resulting in quiet, smooth, and durable performance.

Automatic Arm Locking Mechanism

• Activates when the vehicle is lifted. Increases workplace safety and allows technicians to focus on the task without manually locking the arms.

Easy Adjustment

• Lifting points can be quickly adjusted without additional tools. The height adjustment mechanism ensures accurate positioning of the supports for various vehicle models.
